Facility

The Manufacturing unit is located in the prominent KIADB Industrial Area of Hi-Tech, Defence & Aerospace Park, Devanahalli, Bangalore. We are located adjacent to Kempegowda International Airport, Bangalore and in proximity to Yelahanka Airbase of the IAF which hosts Aero India – Asia’s premier Air Show. The machines/equipments installed are as follows:

Infrastructure

  • 10,000sft of facility with Industrial grade floor structure with epoxy coating.
  • Space available for expansion 5000 + sft.
  • 175 KVa connected power
  • All machines are backed up with UPS to ensure continuity.
  • Best practices for material storage and quarantine facility.
  • Plan for investments in the next 6 months.
    1. CMM
    2. Distributed Numerical Control System (DNC)
    3. ERP
    4. Completely Secure IT Network with cloud back up for data for contingency.

Machinery

Haas VMC Model VF-2

Haas VMC Model VF-4

Haas VMC Model VM-6

Haas VMC Model UMC-750SS

Haas Tool Room Lathe Model TL-1

Conventional Lathe

BFW Vertical Milling Machine VF3.5

Radial Drilling Machine

convention lathe

BFW Vertical Milling Machine VF3.5

CNC Machines

5 Axis

Haas UMC 750SS

  • 762 X 508 X 508 mm
  • Axis: B (tilt) +110˚, -35˚
  • C (rotation): 360˚
  • Capacity: 660 lb/300 kg
  • Spindle Power: 30 hp/22.4 kW
  • Spindle Speed: 15,000 rpm
  • Tool Changer: 40+1

3 Axis VMC


Haas VM 6

  • 1626 X 813 X 762 mm
  • Table Size: 1626x711 mm
  • Spindle Power: 30 hp/22.4 kW
  • Spindle Speed: 12,000 rpm
  • Tool Changer: 20+1

3 Axis VMC


VF-4

  • 1250 X 508 X 508 mm
  • 3 Axis Simultaneous Control
  • Table Size: 1321 x 457 mm
  • Spindle Power: 30 hp/22.4 kW
  • Spindle Speed: 8,100 rpm
  • Tool Changer: 20+1

Quality

Aero Platina is equipped with requisite quality and measurement equipment to meet the stringent needs of Aerospace Industry

List of quality equipment:
  • Granite surface table.
  • Digital and Conventional Vernier.
  • Micrometer.
  • Feeler gauge.
  • Standard pin set.
  • Height gauge Digital & Conventional.
  • Dial indicator.
  • Slip gauge, working set 82pcs.
  • Bevel protractor standard digital.
  • V blocks with grooves.
  • Clamps.
  • Scribers.
  • Bore Gauges
  • Radius gauge.

CNC Programming

SolidCAM software is seamlessly integrated in SOLIDWORKS for 3D modelling and CNC programming. SolidCAM has a built-in & patented iMachining solution with the following features:-

  • 3D mill along with High Speed Machining
  • 5 axis simultaneous milling
  • CNC Turning simulation
  • Tool Path Manager
  • Tool Simulation Module
  • Part, Assembly Modelling
  • Drafting Capabilities
